Features
- Low dark current
- High linearity
- High reliability
- Compliant with RoHS standard
Applications
- Apply to various digital and analog fiber-optic transmission systems
Optical and Electrical Characteristics(Tc=25℃)
|
Parameter |
Symbol |
Test condition |
Min. |
Type |
Max. |
Unit |
|
Optical Wavelength Range |
λ |
1260 |
— |
1620 |
nm |
|
|
Spectral Responsivity |
R |
VR=5V λ=1310nm |
0.8 |
0.88 |
— |
A/W |
|
VR=5V λ=1550nm |
0.85 |
0.93 |
— |
A/W |
||
|
Return loss |
RL |
λ=1310nm |
45 |
— |
— |
dB |
|
λ=1550nm |
40 |
— |
— |
dB |
||
|
Dark Current |
Id |
VR=5V 25℃ |
— |
0.2 |
1.0 |
nA |
|
Capacitance |
C |
VR=5V, F=1MHz |
— |
0.5 |
0.6 |
pF |
|
Breakdown Reverse Voltage |
VBR |
IR=10uA |
30 |
— |
— |
V |
|
ESD |
— |
500 |
— |
— |
V |
Package Dimensions and Pin Description
Unit：mm
Fiber Type：SM 、9/125um 、900um
