Optical and Electrical Characteristics(Tc=25℃)
Parameter |
Symbol |
Test condition |
Min. |
Type |
Max. |
,Unit |
Optical Wavelength Range |
λ |
800 |
— |
1700 |
nm |
|
Active Area |
Φ |
— |
1000 |
— |
um |
|
Spectral Responsivity |
R |
λ=1310nm, Vr=5V |
0.85 |
0.9 |
— |
A/W |
λ=1550nm, Vr=5V |
0.9 |
0.95 |
— |
A/W |
||
Dark Current |
Id |
Vr=5V 25℃ |
— |
— |
5.0 |
nA |
Capacitance |
C |
F=1MHz |
— |
— |
6.0 |
pF |
ESD |
— |
300 |
— |
— |
V |
Pin Description and Package Dimensions
Unit:mm
